30–40W All-in-One Solar Street Light | Integrated Solar LED Road Lighting Manufacturer

All in One Solar Street Light for Outdoor Lighting Projects

If you need a lighting solution that installs fast and works without complexity, the all in one solar street light is a practical option. With the panel, battery and LED integrated into one unit, it helps reduce installation time, avoid wiring issues and keep overall project costs under control. It’s widely used in roads, residential areas and small to medium projects where efficiency and reliability are key. Get Your All in One Solar Street Lighting Solution

All in One Solar Street Light Specifications

Led Source	40W	50W	60W	80W	100W	120W
Mono Solar Panel	18V 60W	18V 70W	18V 80W	18V 100W	18V 130W	18V 140W
LifePO4 Battery	12.8V 18AH	12.8V 24AH	12.8V 30AH	12.8V 36AH	12.8V 48AH	12.8V 78AH
LED (Bridgelux)	3030/96PCS	3030/144PCS	3030/144PCS	3030/192PCS	3030/288PCS	3030/288PCS
Color Temperature	2700K-6500K , RA>70
Brightness	220LM/W
Working Time	12-15hours, 10-12 cloudy/ rainy days
Charging Time	6-8hours
Mounting Caliber	70-76mm ( suggestion )
Working Temperature	-25℃ - +65℃
Body Sensor	160° , >9m , Activated by customer's need
Battery Power Indicators	100%-75%-50%-25%
Fault indicator	RED/BLUE/GREEN
IP Rating/IK Class	IP66/IK09
Mounting Height	6-7m	6-8m	6-8m	8-9m	9-11m	10-12m
Space between 2 lamps	20-25m	20-25m	20-25m	25-30m	30-35m	35-40m
Warranty	3 years / 5 years

What Is an All in One Solar Street Light?

An all in one solar street light is a compact lighting system where all key components are integrated into one fixture:

Solar panel (energy collection)

Lithium battery (energy storage)

LED light source (illumination)

Smart controller (system management)

This integrated design eliminates external wiring and simplifies installation, making it ideal for fast-deployment lighting projects.

Start Your Solar Street Light Project Today

Types of All in One Solar Street Lights


100W All in One Solar Street Light A 100W All in One Solar Street Light is the ideal power rating for 6-meter poles in residential zones. We’ve optimized the LED driver to balance brightness with thermal management, ensuring the light output remains consistent throughout the night. It’s a precise engineering solution for contractors who need reliable coverage for standard road widths.	All-in-One Solar Parking Lot Lights For commercial areas, Solar Parking Lot Lights (All-in-One) offer a streamlined upgrade path. These units utilize a wide-angle Type III lens to distribute light evenly across expansive bays, reducing the number of poles required. It’s an efficient way to modernize facility lighting while maintaining a clean, cable-free environment.	Integrated Solar Street Lamp with Motion Sensor Our Integrated Solar Street Lamp with Motion Sensor uses high-frequency microwave technology to detect presence. By intelligently adjusting the illumination levels, the system maximizes its operational window. This ensures the all-in-one unit provides full visibility exactly when needed, maintaining high performance during seasonal changes in sunlight.

IP66 Waterproof All in One Solar Light In high-humidity or coastal regions, the IP66 Waterproof All in One Solar Light is essential. We use marine-grade aluminum and specialized gaskets to protect the internal optics and electronics from salt spray and moisture ingress. This robust construction ensures long-term stability in the most demanding outdoor climates.	All in One Solar Street Light for Garden & Pathway Designed for hospitality and landscape projects, the All in One Solar Street Light for Garden & Pathway prioritizes visual comfort. The integrated design eliminates bulky hardware, offering a sleek profile that complements modern architecture. We use specialized diffusers to provide glare-free lighting for pedestrians and recreational spaces.	Integrated LED Solar Light with 5-Day Autonomy To ensure continuous operation, this Integrated LED Solar Light is engineered for extended autonomy. The system is sized to provide a 5-day backup, meaning the lighting remains active even during consecutive overcast periods. It’s the professional choice for projects where uninterrupted night-time visibility is a critical requirement.

Features of All-in-one Solar Street Light

1. Designed by a professional industrial design team, integrating solarpanels, led sources, controller,battery, human body induction, and housing.

2. Adjustable angle mounting bracket, suitable for a variety of modelinglamp pole installationmethods.

3. Intelligent power adjustment, automatic weather judgment, reasonableplanning of dischargerules.

4. Inteligent charging and discharging management, soft and hard doubleprotection of charging anddischarging and intelligent equalization technology,battery cycles more than 2000 times

5. Smart remote control, equipped with drone remote control, ultra-longremote control distance of30 meters, can pass through obstacles, and can setfour lighting modes at will.

6. High-efficiency LED chips can reach 220L/W, which is more than twice theaverage brightness ofordinary LED light sources, with a luminous angle of 140degrees, and a wider irradiation area.

7. The whole lamp adopts modular minimalist design, easy disassembly,installation, andtransportation.

Microwave Motion Sensor
The third-generation sensor technology – microwave motion sensor with patent certificate. Auto-adjust light luminance according to ambient movement, save more energy, then the battery can last more days when cloudy and rainy.

2000 Cycles LiFePO4 Battery
solar street lights are powered by LiFePO4 battery with min 2000 times life cycles, DOD 80%. Which means 8 years lifespan on average. The charge and discharge is managed by both hardware and software.It’s a maintenance-free system.

Bat-wing Lens
bat-wing lens leverage the maximum usage of lumens from solar street light. The professional light distribution can cover a wider area along the road.Reducing the light waste and increase the installation interval between lights (up to 50m), then save the number of light.

WHY CHOOSE US?

HIGH PURITY, HIGH CONDUCTIVITY, LOW ENERGY CONSUMPTION, STRONG CURRENT

LOAD CAPACITY, LOW HEAT GENERATION

why choose me

Manufacturer

STRONG STRENGTH OF BIG BRAND MANUFACTURERS

BUY WITH CONFIDENCE AND NO REGRETS

Manufacturer

OUR ADVANTAGES


CAD Design	3D SceneSimulation Design

Specification &Color Customization	Light distribution curve test

DIALux evo llumination simulation	Oversea Onsite Installation Guidance

Where to Use All-in-One Solar Street Lights

	Residential Streets The Solution: In neighborhoods, you don't want heavy machinery tearing up people's front yards for cables. Our All in One Solar Street Light just clamps onto the pole and it's done. The smart sensor is a lifesaver here—it keeps the integrated solar lamp dim when the street is empty, then kicks into full power the second a car or pedestrian enters the gate. Find the Right Solar Street Light System
	Rural Road Projects The Solution: Most village projects have tight budgets and zero grid access. We built these Integrated Solar Street Lights to be "plug-and-play." You don't need a professional electrician; local workers can install dozens of these solar powered street lamps a day just using a basic ladder. It’s the fastest way to get light into remote areas.
	Public Parks & Gardens The Solution: For parks, aesthetics and safety are everything. There are no messy external wires or bulky boxes to ruin the landscape. The solar panel of this All in One LED Street Light sits flush on top, soaking up the sun all day. It’s a clean, modern look that provides enough light for evening joggers while keeping the installation completely "invisible."
	Parking Lots The Solution: Paving a parking lot is expensive—re-digging it to lay power lines is even worse. Our Integrated Solar Lighting skips the trenching entirely. You get strong, wide-angle light from a single all-in-one unit, making sure security cameras get a clear shot of every corner. It’s a huge win for managers who need to upgrade security overnight.
	Factory & Warehouse Perimeters The Solution: Industrial zones are dusty and tough on gear. We use a rugged aluminum shell so the internal parts of the All in One Solar Lamp stay bone-dry and dust-free. These lights act as your 24/7 silent security guard along the fence line, providing steady LED solar illumination that doesn't flicker, even in the worst storms.
	School Campuses The Solution: Safety is the only priority on a campus. With our Integrated Solar Power system, there are no high-voltage wires underground, meaning zero risk of electrical leaks during the rainy season. The "internal brain" manages the power so the all-in-one street light stays on even if it’s been cloudy for three days straight.
	Construction Sites The Solution: Construction sites change every week. You need a Portable Integrated Solar Light that can move with the job. Since everything is in one box, you can just unscrew the light from one temporary pole and move it to the next. No generators, no diesel costs, and no noise—just reliable solar street lighting for night shifts.
	Farm & Ranch Lighting The Solution: On a large farm, the nearest power outlet might be miles away. These All in One Solar Solutions give you total independence. We use high-quality lithium batteries because they handle the temperature swings of open fields. Whether it’s lighting up a barn or a remote gate, it’s a "set it and forget it" solar lamp for farmers.

Fast response, factory-direct supply, and customized lighting solutions available.

Email: mr.xu@yzldzm.com | Tel: +86 13815843784 | WhatsApp: +86 13815843784

FAQS

1. What exactly is an All-in-One Solar Street Light?

It’s a streamlined design where the solar panel, the battery, and the LED are all built into a single, high-strength housing. Unlike traditional setups with separate parts, the All-in-One Solar Street Light is a self-contained unit that’s much easier to ship and install.

2. Does an All-in-One LED Solar Light work on cloudy days?

Yes. Our All-in-One LED Solar Lights are designed with enough battery capacity to bridge several days of bad weather. The internal system is smart enough to manage the power, ensuring the light stays active even when the sun isn't hitting the panel directly for a day or two.

3. How does the All-in-One Solar Power system know when it’s dark?

The solar panel on top of the All-in-One Solar Power unit acts as a built-in light sensor. It automatically detects when the sun goes down to trigger the LEDs and shuts them off at sunrise to begin the daily recharging cycle.

4. Why should I choose an All-in-One Solar Street Light with a Motion Sensor?

The Motion Sensor is a major advantage for battery longevity. The All-in-One Solar Street Light stays at a low, energy-saving brightness when the area is empty, but instantly switches to 100% full power when it detects movement. This ensures you have maximum light exactly when it’s needed.

5. What is the typical lifespan of an All-in-One Solar Light battery?

We use high-grade Lithium (LiFePO4) batteries in every All-in-One Solar Light. These are much more durable than old-style batteries, typically lasting 5 to 8 years before they need a replacement, depending on the local climate and usage.

6. Do I need to clean the panel on my Integrated Solar Street Lamp?

In most cases, rain will wash away the dust. However, if you are in a very sandy or dry area, a quick wipe of the Integrated Solar Street Lamp’s panel every few months will keep the charging efficiency at its highest level.

7. Is every All-in-One Solar Street Light waterproof?

Quality matters here. Our units are rated IP66 Waterproof, meaning the All-in-One Solar Street Light is completely sealed against dust and heavy rain. It’s built to handle monsoons and coastal storms without any internal damage.

8. What maintenance is required for All-in-One Solar Lighting?

Practically none. Because the All-in-One Solar Lighting system is fully integrated with no external wires to fray or corrode, there’s nothing to fix. It’s a "set it and forget it" solution for most municipal and private projects.

9. Can I control the settings on my All-in-One Solar Lamp?

Yes. Most of our All-in-One Solar Lamps come with a remote control. You can use it to switch between different working modes, like constant brightness or motion-sensor mode, to suit your specific site requirements.

10. When should I use an All-in-One Solar Street Light instead of a split-type?

Choose the All-in-One Solar Street Light for 90% of standard road, park, and parking lot projects where you want a fast, clean, and low-maintenance setup. Split-type lights are usually only for very specialized high-power industrial needs.

Previous : High-Efficiency Integrated Solar LED
High-Efficiency Split Solar Street L : Next
